YG230 connector for double head locomotive
Product overview:
Product parameters:
Rated voltage | 18 pin:220V AC 24 pin:110V AC |
Rated current | 5A |
Contact resistance | ≤1mΩ |
Insulation resistance | ≥5000MΩ |
Withstand voltage | 18 pin:2500V AC 24 pin:1500V AC |
Number of contacts | 18,24 |
Male/Female | |
Service life | >750 cycles |
Insertion and separate force | Single pin separating force:3N~6N (18 pin) Single pin separating force:2N~4N (24 pin) |
Protection level | IP67 |
Operation Temperature | -40℃~+125℃ |
Relative Humidity | 95%(40℃) |
Material | |
Flammability | |
Surface treatment | Paint spray, anodize |
Color | |
Application | Locomotive double head connection |
Package | Carton |
Packaging & Delivery
Packaging Details：Carton
Delivery Time：25 days
