Product Description
Features:
1. Double local oscillator fruquency KU 9.75/10.6
2. Linear polarization and circular polarization
3. Imported Circuit Board Component
4. Shell Material: ABS - nine, aluminum
The industry’s best LO (Local Oscillator) stability
High performance for any application
Excellent availability and short lead times
Easy installation and trial run
High quality weather protection
Beautiful Design
More Details:
Input Frequency | Low Band:10.7-11.7GHz High Band:11.7-12.75GHz |
Output Frequency | Low Band:950-1950MHz High Band:1100-2150MHz |
L.O. Frequency | Low Band:9.75GHz(1MHZ@25℃) High Band:10.6GHz(1MHZ@25℃) |
L.O. Stability | ±1MHz(-40℃to+70℃) |
Noise Figure | 0.1dB |
Conversion Gain | 65dB |
Gain Flatness | ≤±1.5dB |
Input VSWR | 2.5:1(max) |
Output VSWR | 2.0:1(max) |
Output Connector | F-female Connector |
Output Impedance | 75Ω |
Cross Polar Isolation | 20dB(min) |
Supply Voltage | 1)Ca:11.5-14.0V(Vertical Polarization)13VDCtype 16.0-19.0V(Horizontal Polarization)18VDCtype |
Direct Current | 150mA |
Control Signals | 1) Low Band:Ca or Cb(see below) 2) High Band:Cc or Cb(see below) 3) Cc:Continues 22KHz |
Operating Temperature | -40℃to+70℃ |
Storage Temperature | -40℃to+80℃ |
Relative Humidity | 0%-95% |
Phase Noise | 1)-50dBc/Hz@1KHz(max) 2)-75 dBc/Hz@10KHz(max) 3)-95 dBc/Hz@100KHz(max) |
Image Rejection | 45dB(min) |
Company Information
Bowei Electronics is a professional manufacture21 years specialized in LNB, MMDS down converter and Antenna etc. Anhui Bowei Electronics Technology Co., Ltd is a National High-tech Enterprise mainly engaged in the research, development, production, fabrication, marketing of microwave high frequency electronics and over-voltage and over-current protection equipment.
Our products command a good market both at home and abroad. Microwave High Frequency Electronics are mainly exported to Europe, Southeast Asia, Middle East, North America etc. 86 countries and areas. In the domestic markets, Anhui Bowei Electronics services for the national Radio and Television“Hu Hu Tong” Household Project and also supports the digital improvement for Regional Radio and TV Cable Network Companies. Meanwhile, Over-voltage and Over-current Protection Equipment are widely distributed around the country and mostly applied in fields of electricity, petroleum, chemistry, metallurgy, cement and steel.
In the future, Anhui Bowei Electronics will continue to communicate and cooperate with domestic and overseas counterparts in the main products to arrive at the aim of providing our honored customers with more excellent quality products and more superior service.
Why Choose Us
1, Anhui Bowei Electronic Technology Co.,Ltd is a National High-Tech Enterprise mainly engaged in the research, development, production, fabrication, marketing of microwave high frequency electronics, and with more than twenty-year’s experience.
2, Our products command a good market both at home and abroad, Europe, Southeast Asia, Middle East, North America, etc.86 countries and areas.
3, We have these certifications like SGS, CE, ISO9001, etc. so quality can trust.
4, We insist the reasonable price on the premise of the advanced technology and quality assurance.
5, We have educated engineers and after-sale service team for every our customer, and meet their requirements.
6, Our company provide one-stop service for customers, what’s more, vivid experience can prove what is the best.
FAQ
1,Q:Are you a factory or trading company?
A:We are a factory with more than 20 years satellite LNB and MMDS downconverter manufacture experience.
2,Q: What about your products?
A:Our products are assured by the strict QC for each step, so good quality is promised. And our products can design by your requirements.
3,Q:What is the material of your products?
A:The main material of our products is Aluminum.
4,Q:Can you delivery samples before place an order?
A:Yes, but we are not responsible for the freight.
5,Q:What about packing & delivery?
A:We provide the standard trading package, and ships out within 7 working days.
6,Q:What about your service?
A:Factory supply directly, OEM service available.
7,Q:What are my rights as a customer?
A: It is now easier for you to choose only those funeral related items, whether good or services that you want or need and to pay for only those you select as a result of government regulation. You can now compare costs before making any final choices whether you shop the internet, by telephone or in person.
