Specifications
Titanium foil
Gr1,Gr2, Gr4,Gr5,Gr7,Gr9
Thickness: 0.01 to 3mm
Hot/cold rolled, ASTM B265
Different width, bright surface
1.Titanium foil
Gr1,Gr2,Gr5,Gr7,Gr9,Gr12
ASTM B265, 4911, ISO
0.01--3 mm thick
Free sample accepted
2. General introduction
(1)Commercial Pure titanium are Gr1, Gr2, Gr3 and Gr4. Most popular are Gr1 & Gr2. Titanium alloy ar Gr5(Ti-6Al-4V), Gr7(Ti-0.2Pd), Gr9(Ti-3Al-2.5V), Gr12, Gr23.. etc.
(2)Titanium foil is produced as Standard fo ASTM B265.
(3)Surface is silver and bright. Thickness from 0.5mm to 30mm. Length: As your required
(4)Payment Term: T/T or L/C West Union
(5) MOQ : 10 kg
(6) package : Ply wood case for export use or as request
(7) delivery time : 15- 25 days after confirmed
3. Chemical Composition
Chemical Composition:
Grades | Chemical Composition (%) | |||||||||||||||
Main contents | Impurity, not more than | |||||||||||||||
Chemical content | Ti | Al | Sn | Mo | Pd | Ni | V | Fe | C | N | H | O | others | |||
single | total | |||||||||||||||
Gr1 | rest | — | — | — | — | — | — | 0.20 | 0.08 | 0.03 | 0.015 | 0.18 | 0.10 | 0.40 | ||
Gr2 | rest | — | — | — | — | — | — | 0.30 | 0.08 | 0.03 | 0.015 | 0.25 | 0.10 | 0.40 | ||
Gr5 | rest | 5.5- 6.75 | 3.5- 4.5 | 0.40 | 0.08 | 0.05 | 0.015 | 0.20 | 0.10 | 0.40 | ||||||
4. Tolerance control
Thickness within 10% of nominal thickness , width and length ±1mm.
5. Quality Assurance
From titanium sponge to the final products, there are experts and quality control member to supervise. Every piece of titanium finished products will be made the inspection of flaw detection.
We have our own inspection department and guarantee all the products are qualified , and then can be allowed sent to customers. At the same, we have and we accept third party inspection, like Baoti Group.
Specification ( thickness × width × length )
foil: (0.01-0.02)×(30-100)×( ≥500)mm
(0.003-0.09)×(50-300)×( ≥500)mm
band: (0.10-0.30)×(50-300)×( ≥500)mm
(0.40-0.90)×(50-500)×( ≥1000)mm
(0.01-0.02)×(30-100)×( ≥500)mm
(1.0-2.0)×(50-500)×( ≥2000)mm
