RS232 to Ethernet RS485 to RJ45 RS422 to TCP IP Converter Support Modbus RTU to Modbus TCP

1. Product Name: RS232 to Ethernet RS485 to RJ45 RS422 to TCP IP Converter Support Modbus RTU to Modbus TCP

2. Introductions

  ODOT-S4E2 is a solution that provides a communication between Modbus RTU and MODBUS TCP/IP protocols.All the Modbus RTU slave devices, as long as it has RS485 interface, can connect to Modbus TCP/IP network and communicate with TCP clients. So as to realize the low speed serial device connected to the high-speed Ethernet, realizing high speed data transmission.

3.Key Features

 Speed auto-sensing:1200~115200bps.

 Verify mode: no, odd, even.

 Number of slave devices: Max.124(without repeater).

 Buffer size: 6KB.

 Isolation voltage:1500V.

 Operating mode: Transparent transmission mode & address mapping mode(optional), Modbus

 TCP/IP protocol.

 Network protocol: ETHERNET,ARP, IP, TCP, ICMP.

 Serial communication mode: RTU mode and ASCII model is optional.

 Number of Ethernet ports:2 RJ45.

 10M,100M speed auto-sensing
