Diameter 140mm pure titanium welded tube
Diameter 140mm pure titanium welded tube
Product Introduction
NAME | Diameter 140mm pure titanium welded tube |
GRADE | GR1, GR2, GR12 |
STANDARD | ASTM B861, ASTM B862 |
DIMENSION (MM) | OD100~820*3~10*1000~6000mm (Welded tube) |
1. Chemical requirements
Grade | N | C | H | Fe | O | Mo | Ni | Ti |
Gr1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | bal | ||
Gr2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | bal | ||
Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.2~0.4 | 0.6~0.9 |
2. Mechanical Properties
Grade | Tensile strength (δ5MPa) | Residual elongation stress (δ0.2MPa) | Elongation δ (%) |
Gr1 | >240 | 140~310 | >25 |
Gr2 | >400 | 275~450 | >20 |
Gr12 | >460 | >300 | >18 |
Applications
Chemical pipeline;
Coiling pipe; petroleum pipeline;
Sea farming; electroplating equipment;
Fluid Transportation Piping
Products Details
Baoji Changli Special Metal Co., Ltd.
- Phone: +86 0917-3371222
- Business Type: Manufacturer
- Location: China
- Main Products: MMO Titanium Anode,Titanium Tube,Zirconium Tube and Nickel Tube,Titanium Plate and Nickel Plate
- Total Employees:Less than 100 people
- Year Established:
- Export Markets:
- Total Annual Revenue:
